Xerox Phaser 4600 Service Manual

04/2016
2-54
Phaser 4600/4620/4622 Printer Service Manual
09-700-00, 09-800-00, 09-810-00
Revised
2 Status Indicator RAPS
09-700-00 Toner Supply Error RAP
09-700-00 Inadequate toner supply to the Drum Cartridge.
BSD-Reference: WD 5
Initial Actions
• Check the Toner Cartridge for seal tape.
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Toner Cartridge. The Toner Cartridge is installed correctly and the seal tape is
removed.
YN
Remove seal tape if present, then gently agitate the Toner Cartridge and install.
Remove the Right Cover (REP 28.2) and check the Top Door linkage. The linkage is con-
nected and operates freely when the Top Door is raised and lowered.
YN
Repair the Top Door linkage.
Test the toner motor in the Main Drive Assembly. The motor rotates.
YN
Reseat CN9 on the MCU Board, then retest the toner motor. The motor rotates.
YN
Replace the Main Drive Assembly, REP 4.1.
Reassemble and perform SCP 6 Final Actions.
Check all connections between the MCU Board and Main Drive Assembly. The harnesses
are connected and undamaged.
YN
Repair or reconnect the harness.
Replace these components in order until the error is corrected.
1. Toner Cartridge
2. Main Drive Assembly, PL 4.10 Item 1
3. MCU Board, PL 3.10 Item 3
09-800-00, 09-810-00 Invalid Toner Cartridge RAP
09-800-00 Invalid Toner Cartridge detected. Unmatched area code, or CRU plan code error.
09-810-00 Non-Xerox Toner Cartridge detected.
BSD-Reference: WD 7
Initial Actions
• Install a genuine Xerox Toner Cartridge.
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Replace the Toner Cartridge with a genuine Xerox cartridge with the proper SKU. The error
message is displayed.
YN
Perform SCP 6 Final Actions.
Check the Toner Cartridge CRUM connector. The connector is clean and undamaged.
YN
Clean or repair the toner CRUM connector.
Remove the Left Cover (REP 28.3) and check toner CRUM harness connections and condi-
tion. The harness is clean, connected and undamaged.
YN
Repair or reconnect the harness.
Replace these components in order until the error is corrected.
1. Toner Cartridge
2. Joint Board, PL 9.15 Item 7
3. MCU Board, PL 3.10 Item 3
