Xerox Phaser 4600 Service Manual

04/2016
2-55
Phaser 4600/4620/4622 Printer Service Manual
09-900-00, 09-910-00, 09-920-00
2 Status Indicator RAPS
Revised
09-900-00, 09-910-00 Invalid Drum Cartridge RAP
09-900-00 Non-Xerox Drum Cartridge detected.
09-910-00 Non-Xerox Drum Cartridge detected.
BSD-Reference: WD 6
Initial Actions
• Install a genuine Xerox Drum Cartridge.
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Replace the Drum Cartridge with a genuine Xerox cartridge with the proper SKU. The error
message is displayed.
YN
Perform SCP 6 Final Actions.
Check the Drum Cartridge CRUM connector. The connector is clean and undamaged.
YN
Clean or repair the CRUM connector.
Remove the Right Cover (REP 28.2) and reseat CN16 on the MCU Board. The error mes-
sage is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Drum Cartridge
2. MCU Board, PL 3.10 Item 3
09-920-00 Transfer Unit Error RAP
09-910-00 The Transfer Roller high voltage contact point is not connected or is dirty.
BSD-Reference: WD 11
Initial Actions
• Reseat the Transfer Roller.
• Clean the high voltage contact.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Remove the Transfer Roller and inspect the high voltage contact point. The contact is clean
and undamaged.
YN
Replace the Transfer Roller.
Select dC330 codes 09-300 and 09-310 to check Transfer Roller bias voltage. The reading is
within the operating range.
YN
Remove the Left Cover (REP 28.3) and check the high voltage connection to the HVPS.
The harness is clean, connected and undamaged.
YN
Repair or connect the harness.
Replace the HVPS, REP 1.4.
Replace these components in order until the error is corrected.
1. Transfer Roller, PL 9.10 Item 2
2. HVPS, PL 1.10 Item 1
