Xerox Phaser 6125 Service Manual

4-14 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
Tone Correction Tone Correction
■ ON *
■ OFF
<Press the Up or Down
button to switch Tone
Correction On/Off>
<Press the Set button to
save the setting and
move one level up the
menu>
<Press the Cancel button
to move one level up the
menu without saving the
value>
Controls TRC in conjunction with
process control to keep the printer
density constant. This function is
implemented to turn Off tone
correction control in case correction
exceeds the limit due to machine-to-
machine variation.
Sets the printer Tone Correction mode
On/Off.
Note: When the Tone Correction has
been changed, an “*” is displayed next
to the text.
Note: This information can be
initialized by Initialize NVM (Printer
Menu > Admin Menu > Maintenance
Mode > Initialize NVM).
Display
Counter
Not used in this printer.
Hex Dump HexDump
■ OFF *
■ ON
<Press the Up or Down
button to switch
HexDump On/Off>
<Press the Set button to
save the setting and
move one level up the
menu>
<Press the Cancel button
to move one level up the
menu without saving the
value>
Displays the current HexDump On/Off
information and sets mode On/Off.
Note: This information is initialized by
Clear All NVM.
Note: When the Counter Type has been
changed, an “*” is displayed next to
the text.
Pixel Counter Pixel Counter
■ Y: nn.n
■ C: nn.n
■ M: nn.n
■ K: nn.n
<Press the Set or Cancel
button to move one level
up the menu>
Displays the ratio (% used) of the
number of pixel per C/M/Y/K counted
by the Controller to A4 size area except
4 mm area from the edge on the last
page print.
■ 100% = empty Toner Cartridge
The value is rounded off to one decimal
place.
For B/W print, only K is displayed.
The ranges are from 0-100% for each
color (CMYK).
Configuration
■ Not used in this printer.
Counter Type Not used in this printer.
Test Control Panel Display Test Description

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
