Xerox Phaser 6125 Service Manual

Phaser 6130 Color Laser Printer Service Manual I – 1
Index
Index
A
abbreviations
error messages
, 3-5
Phaser 6130
, A-6
AC power
plug/jack locator, 10-10
troubleshooting
, 4-40
ADC (CTD) error
, 3-51
ADC Sensor
control function
, 2-36
description
, 2-23
adjustments
color registration
, 6-2
resetting Fuser life counter
, 6-5
setting parameter
, 6-7
AMPV
, 1-11
ASIC error
, 3-24
B
Bias Charge Roller (BCR), 2-4
Bias Transfer Roller (BTR)
, 2-9
black and white mode
, 2-40
boot controller, firmware update
, A-3
button functions, control panel
, 1-6
C
calibrations
initializing NVM
, 6-6
initializing print meter
, 6-6
chain link code
description, 3-2
message summary
, 3-6
check sum error
, 3-21
cleaning
tools
, 7-2
clearances
, 1-17
Clutch
Registration
, 2-20
collation
, 1-21
color mode switching
, 2-29
color registration
, 2-36
adjustment
, 6-2
adjustments
auto adjustment
, 6-3
disabling
, 6-3
enabling
, 6-3
manual adjustment
, 6-4
configuration page
, 1-24
consumables
Toner Cartridge
description
, 1-10
part number
, 9-25
Control Panel
buttons, 1-6
LED states
, 1-7
operation
, 2-31
plug/jack locator
, 10-8
shortcuts
, 1-7
troubleshooting
, 4-37
Control Panel Harness
removal, 8-54
controller error
, 3-24
controller functions
, 1-20
information pages
, 1-24
job control
, 1-20
maintenance function
, 1-23
non-genuine mode
, 1-22
toner remaining
, 1-23
counters
billing print, 1-22
Cover
front, removal
, 8-19
left side, removal
, 8-17
output tray extension, removal
, 8-15
rear, removal
, 8-18
right side, removal
, 8-16
toner access door, removal
, 8-11
top, removal
, 8-14
covers
removal
, 8-11
CRUM Connector
location, 2-26
operation
, 2-26
D
DC power
troubleshooting
, 4-41
Deep Sleep Mode
, 10-18

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
