Xerox Phaser 8400 Service Manual

General Troubleshooting 4-7
Control Panel
Buttons
Monitors Control Panel buttons and
reports button presses.
Exercise Menu
A submenu containing a set of functions for actively causing mechanical actions which
may then be observed.
Activators Menu Pulses the specified activator to cause
it to generate some sound or motion.
Exercise All Cycles each of the listed activators 4
times in sequence until interrupted by a
Control Panel button press.
Tray 1 P i c k
Solenoid
Cycles the activator repeatedly until
interrupted by a Control Panel button
press.
Tray 2 P i c k
Clutch
Cycles the activator repeatedly until
interrupted by a Control Panel button
press.
Tray 3 P i c k
Clutch
Cycles the activator repeatedly until
interrupted by a Control Panel button
press. If not installed generates an
“Option not detected” message.
Tray 4 P i c k
Clutch
Cycles the activator repeatedly until
interrupted by a Control Panel button
press. If not installed generates an
“Option not detected” message.
Deskew Clutch Cycles the activator repeatedly until
interrupted by a Control Panel button
press.
Pre-heater
Solenoid (8500/
8550)
Cycles the preheater solenoid until
interrupted by pressing the Control
Panel button.
Strip Solenoid Cycles the activator repeatedly until
interrupted by pressing the Control
Panel button.
Tilt Solenoid
(8500/8550)
Cycles the tilt solenoid until interrupted
by pressing the Control Panel button.
Head
Maintenance
Clutch
Cycles the activator repeatedly until
interrupted by a Control Panel button
press.
Menu Map (Continued)
Menu Description
