4-8 Phaser 8400/8500/8550 Color Printer
Purge Vent
Solenoid
Cycles the activator repeatedly until
interrupted by a Control Panel button
press.
110V/220V Drum
Heater Relay(s)
Cycles the activator repeatedly until
interrupted by a Control Panel button
press.
Exercise Motors/
Shafts Menu
These functions drive the specified
motor or shaft sufficiently to generate
easily observed motion without making
substantial change to the state of the
printer.
Exercise All Cycles each of the listed motors/shafts
3 times in sequence until interrupted by
a Control Panel button press.
Process Motor Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Y-axis Motor Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
X-axis Motor Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Purge Pump
Motor
Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Drum Fan Motor Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Media Path
Motor Fan Motor
Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Media Path
Motor & Shafts
Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Transfix Cam
Shaft
Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Drum
Maintenance
Cam Shaft
Cycles the motor/shaft repeatedly until
interrupted by a Control Panel button
press.
Menu Map (Continued)
Menu Description
