4-28 Phaser 8400/8500/8550 Color Printer
8 Exited Interval (us) Reports the interval from the time
the engine software is
commanded to start the exit
process until the Exit sensor
deactivates.
Paper Trail Edge Times
Paper is picked and moved through either the simplex or duplex paper path to determine the
paper trailing edge arrival time at each paper path sensor. R values have alternate definitions or
are unused depending on the pick tray and if simplex or duplex path was selected.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
Common
0 Tray Reports the tray from which the
test paper was picked.
1 Paper Size Reports the size of the picked
paper.
Tray 4 Pick
2 Tray 4 Pick Trailing
Edge Interval (us)
Reports the interval from the time
the engine software is
commanded to start the tray 4
pick process until the Tray 4 Pick
sensor deactivates.
Tray 3 Pick
3 Tray 3 Pick Trailing
Edge Interval (us)
Reports the interval from the time
the engine software is
commanded to start the tray 3
pick process until the Tray 3 Pick
sensor deactivates.
Tray 2 Pick
2Unused
Paper Lead Edge Times (Continued)
Paper is picked and moved through either simplex or duplex paper path to determine leading
edge arrival time at each paper path sensor. R values have alternate definitions or are unused
depending on the pick tray and if simplex or duplex path was selected.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
