Xerox Phaser 8400 Service Manual

General Troubleshooting 4-29
3Unused
Tray 1 Pick
2Unused
3Unused
Common
4 Deskew Trailing
Edge Interval (us)
Reports the interval from the time
the engine software is
commanded to start the transfix
process until the Deskew sensor
deactivates. (part way through
the paper transfix motion).
5 Preheat Trailing
Edge Interval (us)
Reports the interval from the time
the engine software is
commanded to start the transfix
process until the Preheat sensor
deactivates. (part way through
the paper transfix motion).
6 Strip Trailing Edge
Interval (us)
Reports the interval from the time
the engine software is
commanded to start the exit
process until the Strip sensor
deactivates (part way through the
paper exit motion).
Simplex Path
7 Exit Trailing Edge
Interval (us)
Reports the interval from the time
the engine software is
commanded to start the duplex
pick process until the Exit sensor
deactivates.
Paper Trail Edge Times (Continued)
Paper is picked and moved through either the simplex or duplex paper path to determine the
paper trailing edge arrival time at each paper path sensor. R values have alternate definitions or
are unused depending on the pick tray and if simplex or duplex path was selected.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
