4-30 Phaser 8400/8500/8550 Color Printer
Paper Sensor Bounce Times
Paper is picked and moved through either the simplex paper path to determine the paper trailing
edge bounce interval at each paper path sensor. R values have alternate definitions or are
unused depending on the pick tray and if simplex or duplex path was selected.
R# Definition
Typical
Value
(8400)
Typical
Value
(8500/
8550) Actions
Common
0 Tray Reports the tray from which the
paper was picked.
1 Paper Size Reports size of the picked paper.
Tray 4 Pick
2 Tray 4 Pick Bounce
Interval (us)
Reports the interval during which
the Tray 4 Pick sensor bounces
following the passage of the
paper trailing edge.
Tray 3 Pick
3 Tray 3 Pick Bounce
Interval (us)
Reports the interval during which
the Tray 3 pick sensor bounces
following the passage of the
paper trailing edge.
Tray 2 Pick
2unused
3unused
Tray 1 Pick
2unused
3unused
Common
4 Deskew Bounce
Interval (us)
Reports the interval during which
the Deskew sensor bounces
following the passage of the
paper trailing edge.
