No. Parameter Name Setting Range Default
E2-01 Motor Rated Current
10% to 200% of the drive
rated current
<1>
Determined by
C6-01 and o2-04
<1> Display is in the following units:
2A0004 to 2A0040, 4A0002 to 4A0023, and 5A0007 to 5A0017: 0.01 A units.
2A0056 to 2A0415, 4A0031 to 4A0675, and 5A0022 to 5A0242: 0.1 A units.
4A0930 and 4A1200: 1 A units.
Note:
An oPE02 error will occur if E2-01 ≤ E2-03. Set E2-03 correctly to prevent this error.
n
H1-01 to H1-08: Functions for Terminals S1 to S8
These parameters assign functions to the multi-function digital inputs. The various functions and settings are listed in Table
4.26.
No. Parameter Name
Setting
Range
Default
H1-01 Multi-Function Digital Input Terminal S1 Function Selection 1 to 9F
40 (F)
<1>
: Forward Run Command (2-Wire sequence)
H1-02 Multi-Function Digital Input Terminal S2 Function Selection 1 to 9F
41 (F)
<1>
: Reverse Run Command (2-Wire sequence)
H1-03 Multi-Function Digital Input Terminal S3 Function Selection 0 to 9F 24: External Fault
H1-04 Multi-Function Digital Input Terminal S4 Function Selection 0 to 9F 14: Fault Reset
H1-05 Multi-Function Digital Input Terminal S5 Function Selection 0 to 9F
3 (0)
<1>
: Multi-Step Speed Reference 1
H1-06 Multi-Function Digital Input Terminal S6 Function Selection 0 to 9F
4 (3)
<1>
: Multi-Step Speed Reference 2
H1-07 Multi-Function Digital Input Terminal S7 Function Selection 0 to 9F
6 (4)
<1>
: Jog Reference Selection
H1-08 Multi-Function Digital Input Terminal S8 Function Selection 0 to 9F 8: External Baseblock Command
<1> Number appearing in parenthesis is the default value after performing a 3-Wire initialization (A1-03 = 3330).
Table 4.26
Multi-Function Digital Input Terminal Settings
Setting Function Page
0 3-Wire Sequence 153
1 LOCAL/REMOTE Selection –
2 External Reference 1/2 Selection –
3 Multi-Step Speed Reference 1
–4 Multi-Step Speed Reference 2
5 Multi-Step Speed Reference 3
6 Jog reference Selection –
7 Accel/Decel Time Selection 1 –
8 Baseblock Command (N.O.)
–
9 Baseblock Command (N.C.)
A Accel/Decel Ramp Hold –
B Drive Overheat Alarm (oH2) –
C Analog Terminal Input Selection –
D PG Encoder Disable –
E ASR integral reset –
F Through Mode –
10 Up Command
–
11 Down Command
12 Forward Jog
–
13 Reverse Jog
14 Fault Reset –
15 Fast Stop (N.O.) –
16 Motor 2 Selection –
17 Fast Stop (N.C.) –
18 Timer Function Input –
19 PID Disable –
Setting Function Page
1A Accel/Decel Time Selection 2 –
1B Program Lockout –
1E Reference Sample Hold –
20 to 2F External Fault –
30 PID Integral Reset –
31 PID Integral Hold –
32 Multi-Step Speed Reference 4 –
34 PID Soft Starter Cancel –
35 PID Input Level Selection –
40 Forward Run Command (2-Wire sequence)
–
41 Reverse Run Command (2-Wire sequence)
42 Run Command (2-Wire sequence 2)
–
43 FWD/REV Command (2-Wire sequence 2)
44 Offset Frequency 1
–45 Offset Frequency 2
46 Offset Frequency 3
47 Node Setup –
60 DC Injection Braking Command –
61 External Speed Search Command 1 –
62 External Speed Search Command 2 –
63 Field Weakening –
65 KEB Ride-Thru 1 (N.C.)
–
66 KEB Ride-Thru 1 (N.O.)
67 Communications Test Mode –
68 High Slip Braking (HSB) –
6A Drive Enabled –
4.6 Basic Drive Setup Adjustments
152
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
