YASKAWA E-7S SERVOPACK SGD7S - Page 132

4.4 Wiring Servomotors
4.4.3 Wiring the SERVOPACK to the Encoder
4-32
 SL700, SL710, SL720, and SL730
• MJ620-T13 Interpolator
* represents a shielded twisted-pair cable.
*
PS
/PS
PG0V
5
6
5
6
2
2
1
12, 14, 16
CN2
+5 V0 V
U
V
W
M
External power supply
Interpolator
Linear encoder
Shield
Connector
shell
Head
Cable from
Magnescale Co., Ltd.
Connector
shell
SERVOPACK
