1.7 Combinations of SERVOPACKs and Servomotors
1.7.3 Combinations of Linear Servomotors and SERVOPACKs
1-18
1.7.3 Combinations of Linear Servomotors and SERVOPACKs
Linear Servomotor Model
Rated Force
[N]
Instantaneous
Maximum Force
[N]
SERVOPACK Model
SGD7S-
SGLG
(Coreless), Used
with Standard-
Force Magnetic
Way
SGLGW-30A050C 12.5 40 R70A or R70F
SGLGW-30A080C 25 80
R90A or R90F
SGLGW-40A140C 47 140
SGLGW-40A253C 93 280 1R6A or 2R1F
SGLGW-40A365C 140 420 2R8A or 2R8F
SGLGW-60A140C 70 220 1R6A or 2R1F
SGLGW-60A253C 140 440 2R8A or 2R8F
SGLGW-60A365C 210 660 5R5A
SGLGW-90A200C 325 1300 120A
SGLGW-90A370C 550 2200 180A
SGLGW-90A535C 750 3000 200A
SGLG
(Coreless), Used
with High-Force
Magnetic Way
SGLGW-40A140C 57 230 1R6A or 2R1F
SGLGW-40A253C 114 460 2R8A or 2R8F
SGLGW-40A365C 171 690 3R8A
SGLGW-60A140C 85 360 1R6A or 2R1F
SGLGW-60A253C 170 720 3R8A
SGLGW-60A365C 255 1080 7R6A
SGLF
(With F-type Iron
Cores)
SGLFW-20A090A 25 86
1R6A or 2R1FSGLFW-20A120A 40 125
SGLFW-35A120A 80 220
SGLFW-35A230A 160 440 3R8A
SGLFW-50A200B 280 600 5R5A
SGLFW-50A380B
560 1200 120A
SGLFW-1ZA200B
SGLFW-1ZA380B 1120 2400 200A
SGLFW2-30A070A 45 135
1R6A or 2R1F
SGLFW2-30A120A 90 270
SGLFW2-30A230A*
180 540 3R8A
170 500 2R8A or 2R8F
SGLFW2-45A200A 280 840 5R5A
SGLFW2-45A380A* 560
1680 180A
1500
120A
SGLFW2-90A200A 560 1680
SGLFW2-90A380A 1120 3360
200A
SGLFW2-1DA380A 1680 5040
Continued on next page.
