This chapter provides information on installing SERVO-
PACKs and INDEXER Modules in the required locations.
3.1
Installation Precautions . . . . . . . . . . . . . . . . 3-2
3.2
Attaching the INDEXER Module to the SERVOPACK . . 3-3
3.3
Mounting Types and Orientation . . . . . . . . . 3-4
3.4
Mounting Hole Dimensions . . . . . . . . . . . . . 3-5
3.5
Mounting Interval . . . . . . . . . . . . . . . . . . . . 3-7
3.5.1 Installing One SERVOPACK in a Control Panel . . 3-7
3.5.2 Installing More Than One SERVOPACK
in a Control Panel . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.6
Monitoring the Installation Environment . . . 3-8
3.7
EMC Installation Conditions . . . . . . . . . . . . 3-9
Installation
3
