1.7 Combinations of SERVOPACKs and Servomotors
1.7.1 Combinations of Rotary Servomotors and SERVOPACKs
1-15
1
Basic Information
1.7 Combinations of SERVOPACKs and Servomotors
1.7.1 Combinations of Rotary Servomotors and SERVOPACKs
* The capacity depends on the SERVOPACK that is used with the Servomotor.
Rotary Servomotor Model Capacity
SERVOPACK Model
SGD7S-
SGMMV
(Low Inertia, Ultra-
small Capacity),
3,000 min
-1
SGMMV-A1A 10 W
R90A or R90F
SGMMV-A2A 20 W
SGMMV-A3A 30 W 1R6A or 2R1F
SGM7J
(Medium Inertia,
Small Capacity),
3,000 min
-1
SGM7J-A5A 50 W R70A or R70F
SGM7J-01A 100 W R90A or R90F
SGM7J-C2A 150 W
1R6A or 2R1F
SGM7J-02A 200 W
SGM7J-04A 400 W 2R8A or 2R8F
SGM7J-06A 600 W
5R5A
SGM7J-08A 750 W
SGM7A
(Low Inertia, Small
Capacity),
3,000 min
-1
SGM7A-A5A 50 W R70A or R70F
SGM7A-01A 100 W R90A or R90F
SGM7A-C2A 150 W
1R6A or 2R1F
SGM7A-02A 200 W
SGM7A-04A 400 W 2R8A or 2R8F
SGM7A-06A 600 W
5R5A
SGM7A-08A 750 W
SGM7A-10A 1.0 kW
120A
SGM7A-15A 1.5 kW
SGM7A-20A 2.0 kW 180A
SGM7A-25A 2.5 kW
200A
SGM7A-30A 3.0 kW
SGM7A-40A 4.0 kW
330A
SGM7A-50A 5.0 kW
SGM7A-70A 7.0 kW 550A
SGM7P
(Medium Inertia,
Flat),
3,000 min
-1
SGM7P-01A 100 W R90A or R90F
SGM7P-02A 200 W 2R8A or 2R1F
SGM7P-04A 400 W 2R8A or 2R8F
SGM7P-08A 750 W 5R5A
SGM7P-15A 1.5 kW 120A
SGM7G
(Medium Inertia,
Medium Capacity),
1,500 min
-1
SGM7G-03A 300 W
3R8A
SGM7G-05A 450 W
SGM7G-09A 850 W 7R6A
SGM7G-13A 1.3 kW 120A
SGM7G-20A 1.8 kW 180A
SGM7G-30A*
2.4 kW 200A
2.9 kW
330A
SGM7G-44A 4.4 kW
SGM7G-55A 5.5 kW 470A
SGM7G-75A 7.5 kW 550A
SGM7G-1AA 11 kW 590A
SGM7G-1EA 15 kW 780A
