8.4 Tuning-less Function
8.4.3 Troubleshooting Alarms
8-13
8
Tuning
3. Click the or Button to adjust the response level setting. Increase the response
level setting to increase the response. Decrease the response level setting to suppress
vibration.
The default response level setting is 4.
4. Click the Completed Button.
The adjustment results will be saved in the SERVOPACK.
 Related Parameters
 Tuning-less Rigidity Level
If you use tuning-less type 1 or 2 (Pn14F = n.0 or n.1), set the tuning-less level to
between 0 and 4 (Pn170 = n.0 to n.4). Do not set the tuning-less level to between
5 and 7 (Pn170 = n.5 to n.7).

Tuning-less Load Level
8.4.3 Troubleshooting Alarms
An A.521 alarm (Autotuning Alarm) will occur if a resonant sound occurs or if excessive vibra-
tion occurs during position control. If an alarm occurs, implement the following measures.
• Resonant Sound
Decrease the setting of Pn170 = n.X or the setting of Pn170 = n.X.
• Excessive Vibration during Position Control
Increase the setting of Pn170 = n.X or decrease the setting of Pn170 = n.X.
Response Level Setting Description Remarks
7 Response level: High
You cannot select these levels if tuning-less type 1 or 2
(Pn14F = n.0 or n.1) is used.
6
5
4 (default setting)
−
3
2
1
0 Response level: Low
Parameter Description When Enabled Classification
Pn170
n.0 Tuning-less rigidity level 0 (low rigidity)
Immediately Setup
n.1 Tuning-less rigidity level 1
n.2 Tuning-less rigidity level 2
n.3 Tuning-less rigidity level 3
n.4
(default setting)
Tuning-less rigidity level 4
n.5 Tuning-less rigidity level 5
n.
6 Tuning-less rigidity level 6
n.7 Tuning-less rigidity level 7 (high rigidity)
Parameter Description When Enabled Classification
Pn170
n.0
 Tuning-less load level 0
Immediately Setup
n.1
(default setting)
Tuning-less load level 1
n.2 Tuning-less load level 2
