1.7 Combinations of SERVOPACKs and Servomotors
1.7.2 Combinations of Direct Drive Servomotors and SERVOPACKs
1-17
1
Basic Information
* Use derated values for this combination. Refer to the following catalog for information on derating values.
AC Servo Drives Σ-7 Series (Catalog No.: KAEP S800001 23)
SGMCS
(Small Capacity,
Coreless,
Inner Rotor)
SGMCS-02B 2 6
2R8A or 2R1FSGMCS-05B 5 15
SGMCS-07B 7 21
SGMCS-04C 4 12
2R8A or 2R8F
SGMCS-10C 10 30
SGMCS-14C 14 42
SGMCS-08D 8 24
SGMCS-17D 17 51
SGMCS-25D 25 75
SGMCS-16E 16 48
5R5A
SGMCS-35E 35 105
SGMCS
(Medium Capacity,
With Core,
Inner Rotor)
SGMCS-45M 45 135 7R6A
SGMCS-80M 80 240
120A
SGMCS-80N 80 240
SGMCS-1AM 110 330 180A
SGMCS-1EN 150 450
200A
SGMCS-2ZN 200 600
Continued from previous page.
Direct Drive Servomotor Model
Rated Torque
[N·m]
Instantaneous
Maximum Torque
[N·m]
SERVOPACK Model
SGD7S-
