2.3 External Dimensions
2.3.3 INDEXER Module Dimensions and Connector Specifications
2-26
• Three-phase, 200 VAC: SGD7S-590A and -780A
2.3.3 INDEXER Module Dimensions and Connector
Specifications
• External Dimensions
• Connector Specifications
Note: The above connectors or their equivalents are used for the SERVOPACKs.
Unit: mm
Approx. mass: 13.8 kg
Terminals
4 × M6
Terminals
8 × M6
Ground
terminals
2 × M6
(75) (75)136
64
(292.5)
390
375 ±0.5 (mounting pitch)
330 min.
7.5 30
390
4 × M6
Through hole
Exterior
Mounting Hole Diagram
244 min.
(mounting pitch)
235
±
0.5
260
4.5
8
260
Connector
No.
Model
Number
of Pins
Manufacturer
CN11 10236-52A2PL 36 3M Japan Ltd.
CN12 10214-52A2PL 14 3M Japan Ltd.
Approx. mass: 0.2 kg
Unit: mm
CN11
CN12
(10)
20
(60)
(100)
160
(75) 97
