1.7 Combinations of SERVOPACKs and Servomotors
1.7.2 Combinations of Direct Drive Servomotors and SERVOPACKs
1-16
1.7.2 Combinations of Direct Drive Servomotors and
SERVOPACKs
Direct Drive Servomotor Model
Rated Torque
[N·m]
Instantaneous
Maximum Torque
[N·m]
SERVOPACK Model
SGD7S-
SGM7E
(Small Capacity,
Coreless,
Inner Rotor)
SGM7E-02B 2 6
2R8A or 2R1FSGM7E-05B 5 15
SGM7E-07B 7 21
SGM7E-04C 4 12
2R8A or 2R8F
SGM7E-10C 10 30
SGM7E-14C 14 42
SGM7E-08D 8 24
SGM7E-17D 17 51
SGM7E-25D 25 75
SGM7E-16E 16 48
5R5A
SGM7E-35E 35 105
SGM7F
(Small Capacity,
With Core,
Inner Rotor)
SGM7F-02A 2 6
2R8A or 2R1F
SGM7F-05A 5 15
SGM7F-07A 7 21
2R8A or 2R8FSGM7F-04B 4 12
SGM7F-10B 10 30
SGM7F-14B 14 42 5R5A
SGM7F-08C 8 24 2R8A or 2R8F
SGM7F-17C 17 51 5R5A
SGM7F-25C 25 75 7R6A
SGM7F-16D 16 48 5R5A
SGM7F-35D 35 105 7R6A* or 120A
SGM7F
(Medium Capacity,
With Core,
Inner Rotor)
SGM7F-45M 45 135 7R6A
SGM7F-80M 80 240
120A
SGM7F-80N 80 240
SGM7F-1AM 110 330 180A
SGM7F-1EN 150 450
200A
SGM7F-2ZN 200 600
SGMCV (Small
Capacity,
With Core,
Inner Rotor)
SGMCV-04B 4 12
2R8A or 2R8F
SGMCV-10B 10 30
SGMCV-14B 14 42 5R5A
SGMCV-08C 8 24 2R8A or 2R8F
SGMCV-17C 17 51 5R5A
SGMCV-25C 25 75 7R6A
SGMCV-16D 16 48 5R5A
SGMCV-35D 35 105 7R6A* or 120A
Continued on next page.
