13.5 ZONE Outputs
13.5.2 Parameters Related to ZONE Signals
13-54
13.5.2 Parameters Related to ZONE Signals
With the following parameter, the initial status* of the programmable output signals (/POUT0 to
/POUT7) can be set to ZONE signals.
The initial status is the status that exists after the control power supply is turned ON or after
resetting the SERVOPACK.
Note: You can set the ZONE signals for /POUT5 to /POUT7, but the outputs will always be OFF.
13.5.3 SigmaWin+ Procedures
You use the SigmaWin+ to edit, write, and save the ZONE table.
Use the following flow.
Parameter Meaning When Enabled Classification
PnB4F
0000h
(default
setting)
When the control power supply is turned ON or the
SERVOPACK is reset, the /POUT0 to /POUT7 sig-
nals are turned OFF.
After restart Setup
0001h
When control power is turned ON or SERVOPACK
is reset, signals /POUT0 to 7 are ZONE signals.
Editing the ZONE Table
Writing the ZONE Table
Saving the ZONE Table
Checking the Operation of the ZONE Table
Editing the ZONE Table on page 13-55
Writing the ZONE Table on page 13-56
Saving the ZONE Table on page 13-58
