YASKAWA E-7S SERVOPACK SGD7S User Manual

5.16 Setting the Origin of the Absolute Linear Encoder
5.16.1 Preparations
5-50
5.16 Setting the Origin of the Absolute Linear Encoder
You can set any position as the origin in the following Linear Encoders.
• Mitutoyo Corporation
ABS ST780A Series or ST1300 Series
Models: ABS ST78A/ST78AL/ST13
• Renishaw PLC
EVOLUTE Series
Models: EL36Y-
• Renishaw PLC
RESOLUTE Series
Models: RL36Y-
5.16.1 Preparations
Always check the following before you set the origin of an absolute encoder.
• The parameters must not be write prohibited.
• The servo must be OFF.
5.16.2 Applicable Tools
The following table lists the tools that you can use to set the origin of the absolute linear
encoder and the applicable tool functions.
5.16.3 Operating Procedure
Use the following procedure to set the origin of an absolute linear encoder.
1.
Click the Servo Drive Button in the workspace of the Main Window of the SigmaWin+.
2. Select Set Origin in the Menu Dialog Box.
The Set Origin Dialog Box will be displayed.
1. After you set the origin, the /S-RDY (Servo Ready) signal will become inactive because the
system position data was changed. Always turn the SERVOPACK power supply OFF and ON
again.
2. After you set the origin, the Servomotor phase data in the SERVOPACK will be discarded. If
you are using a Linear Servomotor without a Polarity Sensor, execute polarity detection again
to save the Servomotor phase data in the SERVOPACK.
Important
Tool Function Reference
Digital Operator Fn020
Σ-7-Series Digital Operator Operating
Manual (Manual No.: SIEP S800001
33)
SigmaWin+ Setup - Set Origin
Operating Procedure on page 5-50

YASKAWA E-7S SERVOPACK SGD7S Specifications

General

Model	SGD7S
Type	Servo Drive
Category	Servo Drives
Manufacturer	YASKAWA
Humidity	90% RH or less (non-condensing)
Vibration Resistance	5.9 m/s² (0.6 G) at 10 to 60 Hz
Pollution Degree	2
Output Power	Varies by model
Control Method	Speed, Torque, Position Control
Communication Interface	MECHATROLINK-III, EtherCAT
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Encoder Error
Ambient Temperature	0 to +55°C (32 to 131°F)
Storage Temperature	-20 to 85°C
Shock Resistance	49 m/s² (5 G)
Altitude	1000m or less above sea level
Installation	Panel-mounted
Cooling Method	Natural Convection or Forced Air Cooling
Weight	Varies by model
