17.1 Corresponding SERVOPACK and SigmaWin+ Function Names
17.1.1 Corresponding SERVOPACK Utility Function Names
17-2
17.1
Corresponding SERVOPACK and SigmaWin+ Function Names
This section gives the names and numbers of the utility functions and monitor display functions
used by the SERVOPACKs and the names used by the SigmaWin+.
17.1.1
Corresponding SERVOPACK Utility Function Names
SigmaWin+ SERVOPACK
Button in
Menu
Dialog Box
Function Name Fn No. Function Name Serial Command
Setup
Origin Search Fn003 Origin Search
–
Absolute Encoder Reset Fn008
Reset Absolute
Encoder
ABSPGRES
Adjust the Analog Monitor Output
Fn00C
Adjust Analog Monitor
Output Offset
–
Fn00D
Adjust Analog Monitor
Output Gain
–
Adjust the Motor Current Detec-
tion Signal Offsets
Fn00E
Autotune Motor Current
Detection Signal Offset
CURZERO
Fn00F
Manually Adjust Motor
Current Detection Sig-
nal Offset
–
Multiturn Limit Setting Fn013
Multiturn Limit Setting
after Multiturn Limit Dis-
agreement Alarm
MLTLIMSET
Reset Option Module Configura-
tion Error
Fn014
Reset Option Module
Configuration Error
–
Initialize Vibration Detection Level Fn01B
Initialize Vibration
Detection Level
Set Origin Fn020
Set Absolute Linear
Encoder Origin
Software Reset Fn030 Software Reset
Polarity Detection Fn080 Polarity Detection
Tuning-less Level Setting Fn200
Tuning-less Level Set-
ting
Easy FFT Fn206 Easy FFT
ZSET
–FnB09
Set Absolute Encoder
Origin
PRMINIT
Parameters
Initialize FnB0B Initializing Parameters
–
Write Prohibition Setting Fn010
Write Prohibition Set-
ting
–
Setup Wizard – –
–
Tuning
Autotuning without Host Refer-
ence
Fn201
Advanced Autotuning
without Reference
Autotuning with Host Reference Fn202
Advanced Autotuning
with Reference
Custom Tuning Fn203 One-Parameter Tuning
Adjust Anti-resonance Control Fn204
Adjust Anti-resonance
Control
Vibration Suppression Fn205 Vibration Suppression
Moment of Inertia Estimation – –
Continued on next page.
