2.1 Ratings and Specifications
2.1.2 Power Loss in the INDEXER Module
2-5
2
Selecting a SERVOPACK
2.1.2 Power Loss in the INDEXER Module
Power is supplied to the INDEXER Module from the control power supply of the SERVOPACK.
The power loss is given in the following table.
Item Specifications
Min. operating voltage 5.05 V
Max. operating voltage 5.25 V
Max. operating current 500 mA
Max. power loss 2.6 W
