YASKAWA E-7S SERVOPACK SGD7S - Page 65

2.1 Ratings and Specifications
2.1.1 Ratings
2-4
270 VDC
*1. This is the net value at the rated load.
*2. This is 0.25 Arms for the SGD7S-120AE0A008.
* This is the net value at the rated load.
Single-Phase, 100 VAC
* This is the net value at the rated load.
Model SGD7S- R70A R90A 1R6A 2R8A 3R8A 5R5A 7R6A 120A
Maximum Applicable Motor Capacity [kW] 0.05 0.1 0.2 0.4 0.5 0.75 1.0 1.5
Continuous Output Current [Arms] 0.66 0.91 1.6 2.8 3.8 5.5 7.6 11.6
Instantaneous Maximum Output Current
[Arms]
2.1 3.2 5.9 9.3 11.0 16.9 17.0 28.0
Main Circuit
Power Supply 270 VDC to 324 VDC, -15% to +10%
Input Current [Arms]
*1
0.5 1.0 1.5 3.0 3.8 4.9 6.9 11
Control
Power Supply 270 VDC to 324 VDC, -15% to +10%
Input Current [Arms]
*1
0.2 0.2 0.2 0.2 0.2 0.2 0.2
0.2
*2
Power Supply Capacity [kVA]
*1
0.2 0.3 0.6 1 1.4 1.6 2.3 3.2
Power Loss
*1
Main Circuit Power Loss [W] 4.4 5.9 9.8 17.5 23.0 30.7 38.7 55.8
Control Circuit Power Loss [W] 12 12 12 12 14 14 14 15
Total Power Loss [W] 16.4 17.9 21.8 29.5 37.0 44.7 52.7 70.8
Overvoltage Category III
Model SGD7S- 180A 200A 330A 470A 550A 590A 780A
Maximum Applicable Motor Capacity [kW] 2.0 3.0 5.0 6.0 7.5 11.0 15.0
Continuous Output Current [Arms] 18.5 19.6 32.9 46.9 54.7 58.6 78.0
Instantaneous Maximum Output Current
[Arms]
42.0 56.0 84.0 110 130 140 170
Main Circuit
Power Supply 270 VDC to 324 VDC, -15% to +10%
Input Current [Arms]
* 14 20 34 36 48 68 92
Control
Power Supply 270 VDC to 324 VDC, -15% to +10%
Input Current [Arms] * 0.25 0.25 0.3 0.3 0.3 0.4 0.4
Power Supply Capacity [kVA] * 4.0 5.9 7.5 10.7 14.6 21.7 29.6
Power Loss *
Main Circuit Power Loss [W] 82.7 83.5 146.2 211.6 255.3 243.6 343.4
Control Circuit Power Loss [W] 16 16 19 21 21 28 28
Total Power Loss [W] 98.7 99.5 165.2 232.6 276.3 271.6 371.4
Overvoltage Category III
Model SGD7S- R70F R90F 2R1F 2R8F
Maximum Applicable Motor Capacity [kW] 0.05 0.1 0.2 0.4
Continuous Output Current [Arms] 0.66 0.91 2.1 2.8
Instantaneous Maximum Output Current [Arms] 2.1 3.2 6.5 9.3
Main Circuit
Power Supply 100 VAC to 120 VAC, -15% to +10%, 50 Hz/60 Hz
Input Current [Arms]
* 1.5 2.5 5 10
Control
Power Supply 100 VAC to 120 VAC, -15% to +10%, 50 Hz/60 Hz
Input Current [Arms] * 0.38 0.38 0.38 0.38
Power Supply Capacity [kVA]
* 0.2 0.3 0.6 1.4
Power Loss *
Main Circuit Power Loss [W] 5.3 7.8 14.2 26.2
Control Circuit Power Loss [W] 12 12 12 12
Total Power Loss [W] 17.3 19.8 26.2 38.2
Regenera-
tive Resistor
Minimum Allowable Resistance [Ω]40404040
Overvoltage Category III
