17.2 Operation of Digital Operator
17.2.2 Operation of Utility Functions
17-10
17.2.2 Operation of Utility Functions
Utility Functions
The following table shows whether utility functions can be set or not with the digital operator.
Fn No. Function
Possi-
ble/Not
Possible
Remarks and Reference
Fn000 Alarm history display ×
This utility function cannot be used.
Execute FnB0D instead.
Fn002 JOG operation 
Σ-7-Series Servo Drive
Digital Operator
Operating Manual
(Manual No.: SIEP S800001 33)
Fn003 Origin search 
Fn004 Program JOG operation 
Fn005 Initializing parameter settings ×
This utility function cannot be used.
Execute FnB0B instead.
Fn006 Clearing alarm history ×
This utility function cannot be used.
Execute FnB0C instead.
Fn008
Absolute encoder multiturn reset and encoder
alarm reset

Σ-7-Series Servo Drive
Digital Operator
Operating Manual
(Manual No.: SIEP S800001 33)
Fn00C Offset adjustment of analog monitor output 
Fn00D Gain adjustment of analog monitor output 
Fn00E
Automatic offset-signal adjustment of motor
current detection signal

Fn00F
Manual offset-signal adjustment of motor cur-
rent detection signal

Fn010 Write prohibited setting 
Fn011 Servomotor model display 
Fn012 SERVOPACK software version display 
Fn013
Multiturn limit value setting change when a
multiturn limit disagreement alarm (A.CC0)
occurs

Fn014 Resetting configuration error in option module 
Fn01B Vibration detection level initialization 
Fn01E Display of SERVOPACK and servomotor ID 
Fn01F
Display of servomotor ID in feedback option
module

Fn020 Origin setting 
Fn030 Software reset 
Fn080 Polarity detection 
Fn200 Tuning-less levels setting 
Fn201 Advanced autotuning 
Fn202 Advanced autotuning by reference 
Fn203 One-parameter tuning 
Fn204 Anti-resonance control adjustment function 
Fn205 Vibration suppression function 
Fn206 EasyFFT 
Fn207 Online vibration monitor 
FnB03 Program table edit/save 
Program Table Edit/Save (FnB03) on page
17-11
FnB04 ZONE table edit/save 
ZONE Table Edit/Save (FnB04) on page
17-17
 : Possible × : Not possible
Continued on next page.
