Program Table Edit/Save (FnB03)
This function edits and saves program tables. Saving a program table to flash memory after
editing it ensures that the data will be retained even after the control power has been turned
off.

Codes Displayed on the Program Table Editing Screen
Refer to the following section for information on interpreting the displays.
Reading the Screen on page 17-9
 Preparation
The following conditions must be met to edit and save program tables.
• The write-prohibited setting (Fn010) must not be set to write-protect parameters.
• The program must not be running or on hold.
• A program table save operation must not be in progress for any means other than the digital
operator.
• Execution of the RES command must not be in progress.
FnB05 JOG speed table edit/save 
JOG Speed Table Edit/Save (FnB05) on
page 17-19
FnB06 Program table initialization 
Program Table Initialization (FnB06) on
page 17-21
FnB07 ZONE table initialization 
ZONE Table Initialization (FnB07) on page
17-22
FnB08 JOG speed table initialization 
JOG Speed Table Initialization (FnB08) on
page 17-23
FnB09 Absolute encoder origin setting 
Absolute Encoder Origin Setting (FnB09)
on page 17-24
FnB0A INDEXER status monitor 
INDEXER Status Monitor (FnB0A) on page
17-25
FnB0B INDEXER parameter setting initialization 
INDEXER Parameter Setting Initialization
(FnB0B) on page 17-28
FnB0C INDEXER alarm reset 
INDEXER Alarm Reset (FnB0C) on page
17-29
FnB0D INDEXER alarm history display 
INDEXER Alarm History Display (FnB0D)
on page 17-30
 : Possible × : Not possible
PGM
STEP
POS SPD RDST RSPD ACC DEC POUT EVENT LOOP NEXT
0 POS000 SPD000 RDST000 RSPD000 ACC000 DEC000 POUT000 EVT000 LOOP000 NEXT000
1 POS001 SPD001 RDST001 RSPD001 ACC001 DEC001 POUT001 EVT001 LOOP001 NEXT001
… … … … … … … … … … …
255 POS255 SPD255 RDST255 RSPD255 ACC255 DEC255 POUT255 EVT255 LOOP255 NEXT255
