YASKAWA E-7S SERVOPACK SGD7S - Model Designations; Interpreting SERVOPACK Model Numbers

1.6 Model Designations
1.6.1 Interpreting SERVOPACK Model Numbers
1-12
1.6 Model Designations
1.6.1 Interpreting SERVOPACK Model Numbers
*1. You can use these models with either a single-phase or three-phase input.
*2. A model with a single-phase, 200-VAC power supply input is available as a hardware option (model: SGD7S-
120A00A008).
*3. The same SERVOPACKs are used for both Rotary Servomotors and Linear Servomotors.
*4. Refer to the following manual for details.
Σ-7-Series AC Servo Drive Σ-7S/Σ-7W SERVOPACK with Dynamic Brake Hardware Option Specifications Prod-
uct Manual (Manual No.: SIEP S800001 73)
*5. The BTO specification indicates if the SERVOPACK is customized by using the MechatroCloud BTO service.
This service is available on the e-mechatronics website. You need a BTO number to order SERVOPACKs with
customized specifications.
Refer to the following catalog for details on the BTO specification.
AC Servo Drives Σ-7 Series (Manual No.: KAEP S800001 23)
SGD7S
-
R70
A E0 A
001
Σ-7-Series
Σ-7S
SERVOPACKs
4th
digit
1st+2nd+3rd
digits
5th+6th
digits
8th+9th+10th
digits
7th
digit
000
B
11th+12th+13th
digits
14th
digit
001
000
002
SGD7S-120A
008
Single-phase, 200-VAC
power supply input
None
000
None
SpecificationCode
FT/EX Specification
None
B
None
BTO
specification
SpecificationCode
BTO Specification
*5
SGD7S-R70A
to -2R8A
020
*4
No dynamic brake
External dynamic
brake resistor
SGD7S-3R8A
to -780A
SGD7S-R70F
to -2R8F
A 200 VAC
E0
A
Maximum Applicable
Motor Capacity
Voltage
Interface
*3
Code
Code
Specication
Specication
Command option attachable type
Design Revision Order
Hardware Options
Specication
Three-
Phase,
200 VAC
1st+2nd+3rd digits
4th digit
5th+6th digits
7th digit
8th+9th+10th digits
R70
*1
R90
*1
1R6
*1
2R8
*1
3R8
5R5
*1
7R6
120
*2
180
200
330
470
550
590
780
R70
R90
2R1
2R8
0.05 kW
0.1 kW
0.2 kW
0.4 kW
0.5 kW
0.75 kW
1.0 kW
1.5 kW
2.0 kW
3.0 kW
5.0 kW
6.0 kW
7.5 kW
11 kW
15 kW
0.05 kW
0.1 kW
0.2 kW
0.4 kW
Voltage
Code Specication
None
Without options All models
All models
SGD7S-R70A
to -330A
SGD7S-470A
to -780A
Duct-ventilated
Varnished
Rack-mounted
Code
Specication
Applicable
Models
11th+12th+13th digits
14th digit
Single-
Phase,
100 VAC
F 100 VAC
SGD7S-R70F
to -2R8F
