10.3 Parameter Settings for Fully-Closed Loop Control
10.3.7 Analog Monitor Signal Settings
10-10
10.3.7 Analog Monitor Signal Settings
You can monitor the position deviation between the Servomotor and load with an analog moni-
tor.
10.3.8 Setting to Use an External Encoder for Speed Feedback
For fully-closed loop control, you normally set a parameter to specify using the motor encoder
speed (Pn22A = n.0).
If you will use a Direct Drive Servomotor and a high-resolution external encoder, set the param-
eter to specify using the speed of the external encoder (Pn22A = n.1).
Note: This parameter cannot be used if Pn002 is set to n.0 (Do not use external encoder).
Parameter Name Meaning
When
Enabled
Classifi-
cation
Pn006 n.07
Analog Monitor 1
Signal Selection
Position deviation between motor and load
(output unit: 0.01 V/reference unit).
Immedi-
ately
Setup
Pn007 n.07
Analog Monitor 2
Signal Selection
Position deviation between motor and load
(output unit: 0.01 V/reference unit).
Parameter Meaning
When
Enabled
Classification
Pn22A
n.0
(default set-
ting)
Use motor encoder speed.
After restart Setup
n.1
 Use external encoder speed.
