17.2 Operation of Digital Operator
17.2.2 Operation of Utility Functions
17-17
ZONE Table Edit/Save (FnB04)
This function edits and saves ZONE tables. Saving a ZONE table to flash memory after editing
it ensures that the data will be retained even after the control power has been turned off.
Codes Displayed on the ZONE Table Editing Screen
For details on how to read the screen, refer to Reading the Screen on page 17-9.
Preparation
The following conditions must be met to edit and save ZONE tables.
• The write-prohibited setting (Fn010) must not be set to write-protect parameters.
• A ZONE table save operation must not be in progress for any means other than the digital
operator.
Editing ZONE Tables
The operating procedure when setting ZONE N in ZONE number 5 is explained here.
ZONE
Number
ZONE P ZONE N
0 ZP000 ZN000
1 ZP001 ZN001
…
…
…
31 ZP031 ZN031
Step Display after Operation Keys Operation
1
Press the key to open the Utility Function
Mode main menu, and move the cursor with the
keys to select FnB04.
2
Press the key to view the FnB04 operation
screen.
3
Move the cursor using the keys and
keys to select the ZONE table number to
be edited. Refer to the following section for details
on the methods to move the cursor.
Method for Moving the Cursor on page 17-13
4
Press the key to move the cursor to the set-
ting side of the table.
5
Move the cursor using the keys and
change the ZONE boundary values using the
keys.*
6
On pressing the key, the setting is entered
and the cursor returns to the ZONE table number
side.
7
Repeat steps 3 to 6 to set the ZONE table. On completing the setting of all the ZONE tables to be
used, save the ZONE tables to flash memory by following the procedure in
Saving ZONE Tables on
page 17-18.
* If setting is attempted in an operation prohibited state, it will not be possible to change the setting. In this case,
make the setting again by referring to
Preparation on page 17-17.
