6.1 I/O Signals
6.1.1 Input Signals
6-6
/JOGP (Forward Jog Input) Signal
This signal functions as the forward jog operation command.
You can change the setting for the /JOGP signal with PnB05. If you change the setting for the /
JOGP signal, set the /MODE 0/1 signal to OFF (open) (Mode 1).
/JOGN (Reverse Jog Input) Signal
This signal functions as the reverse jog operation command.
You can change the setting for the /JOGN signal with PnB06. If you change the setting for the /JOGN
signal, set the /MODE 0/1 signal to OFF (open) (Mode 1).
/JOG0 to /JOG3 (Jog Speed Table Selection Inputs) Signals
These signals specify the speed in the jog speed table.
You can change the settings for the /JOG0 to /JOG3 signals with PnB07 to PnB0A. If you
change the settings for the /JOG0 to /JOG3 signals, set the /MODE 0/1 signal to OFF (open)
(Mode 1).
Type Signal Pin No. Signal Status Meaning
Input /JOGP CN11-7
ON (closed)
Forward jog operation is performed. Jog opera-
tion is performed as long as the signal is ON.
OFF (open) Stops the jog operation.
Parameter Meaning When Enabled Classification
PnB05
0000h
(default setting)
Executes JOG operation in the forward direction
while the /JOGP signal is ON (closed).
After restart Setup0001h
Executes JOG operation in the forward direction
while the /JOGP signal is OFF (open).
0002h,
0003h
Does not execute JOG operation.
Type Signal Pin No. Signal Status Meaning
Input /JOGN CN11-9
ON (closed)
Reverse jog operation is performed. Jog opera-
tion is performed as long as the signal is ON.
OFF (open) Stops the jog operation.
Parameter Meaning When Enabled Classification
PnB06
0000h
(default setting)
Executes JOG operation in the reverse direction
while the /JOGN signal is ON (closed).
After restart Setup0001h
Executes JOG operation in the reverse direction
while the /JOGN signal is OFF (open).
0002h,
0003h
Does not execute JOG operation.
Type Signal Pin No. Signal Status Meaning
Input
/JOG0
to
/JOG3
CN11-11, -13,
-15, and -17
ON (closed) These signals specify a jog speed that is regis-
tered in the jog speed table. Refer to the follow-
ing section for details.
13.4.3 Jog Speed Table and Speed Selection
Signals on page 13-45
OFF (open)
Parameter Meaning When Enabled Classification
PnB07
PnB08
PnB09
PnB0A
0000h
(default setting)
The /JOG signal is active when ON (closed).
After restart Setup
0001h The /JOG signal is active when OFF (open).
0002h The /JOG signal is always active.
0003h The /JOG signal is always inactive.
To Next Page
