7.6 Convenient Function to Use during Trial Operation
7.6.3 Test without a Motor
7-23
7
Trial Operation
• Linear Servomotors
• Related Parameters
Motor Position and Speed Responses
For a test without a motor, the following responses are simulated for references from the host
controller according to the gain settings for position or speed control.
• Servomotor position
• Motor speed
• External encoder position
The load model will be for a rigid system with the moment of inertia ratio that is set in Pn103.
External Encoder Connection
Status
Information That Is
Used
Source of Information
Connected
External encoder infor-
mation
• Resolution
• Encoder type
Information in the external encoder that is con-
nected
Not connected
• Resolution: 256
• Encoder type: Incremental encoder
Motor Connection
Status
Information That Is Used Source of Information
Connected
Motor information Information in the motor that is connected
Linear encoder informa-
tion
• Resolution
• Encoder pitch
• Encoder type
Information in the linear encoder that is connected
Not connected
Motor information
Setting of Pn000 = n.X (Rotary/Linear Startup
Selection When Encoder Is Not Connected)
Linear encoder informa-
tion
• Resolution
• Encoder pitch
• Encoder type
• Resolution: 256
• Encoder pitch: Setting of Pn282 (Linear Encoder Pitch)
• Encoder type: Setting of Pn00C = n.X (Encoder
Type Selection for Tests without a Motor)
Parameter Meaning When Enabled Classification
Pn000
n.0
(default setting)
When an encoder is not connected, start as
SERVOPACK for Rotary Servomotor.
After restart Setup
n.1
When an encoder is not connected, start as
SERVOPACK for Linear Servomotor.
Pn282
Linear Encoder Pitch
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 6,553,600 0.01 μm0After restartSetup
Parameter Meaning When Enabled Classification
Pn00C
n.0
(default setting)
Use 13 bits as encoder resolution for tests
without a motor.
After restart Setup
n.1
Use 20 bits as encoder resolution for tests
without a motor.
n.2
Use 22 bits as encoder resolution for tests
without a motor.
n.3
Use 24 bits as encoder resolution for tests
without a motor.
n.0
(default setting)
Use an incremental encoder for tests without
a motor.
n.
1
Use an absolute encoder for tests without a
motor.
