8.9 Anti-Resonance Control Adjustment
8.9.6 Suppressing Different Vibration Frequencies with Anti-resonance Control
8-53
8
Tuning
Required Parameter Settings
The following parameter settings are required to use anti-resonance control for more than one
vibration frequency.
Adjustment Procedure for Suppressing Different Vibration
Frequencies with Anti-resonance Control
Use the following procedure to make adjustments to suppress different vibration frequencies
with anti-resonance control.
Parameter Description
When
Enabled
Classifi-
cation
Pn160
n.
0
(default setting)
Do not use anti-resonance control.
After
restart
Setup
n.
1 Use anti-resonance control.
Pn161
Anti-Resonance Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
10 to 20,000 0.1 Hz 1000 Immediately Tuning
Pn162
Anti-Resonance Gain Correction
Setting Range Setting Unit Default Setting When Enabled Classification
1 to 1,000 1% 100 Immediately Tuning
Pn163
Anti-Resonance Damping Gain
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 300 1% 0 Immediately Tuning
Pn164
Anti-Resonance Filter Time Constant 1 Correction
Setting Range Setting Unit Default Setting When Enabled Classification
-1,000 to 1,000 0.01 ms 0 Immediately Tuning
Pn165
Anti-Resonance Filter Time Constant 2 Correction
Setting Range Setting Unit Default Setting When Enabled Classification
-1,000 to 1,000 0.01 ms 0 Immediately Tuning
Pn166
Anti-Resonance Damping Gain 2
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 1% 0 Immediately Tuning
Step Operation
1
Use the gain adjustment and anti-resonance control.
Refer to the following section for details.
8.9.4 Operating Procedure on page 8-50
2
If there is vibration at a higher frequency than the vibration suppressed with anti-resonance
control in step 1, adjust Pn166 (Anti-Resonance Damping Gain 2).
3
Adjust Pn166 (Anti-Resonance Damping Gain 2) while checking to see if vibration reduction is
effective.
To adjust Pn166 (Anti-Resonance Damping Gain 2), increase the setting by 10% at a time start-
ing from the value that resulted in Pn163 (Anti-Resonance Damping Gain) from the adjustment
in step 1.
4
If the vibration disappears, the adjustment is completed.
However, if the vibration does not disappear even when you adjust Pn166 (Anti-Resonance
Damping Gain 2), reduce the tuning level or feedback level until vibration does not occur.
