8.13 Manual Tuning
8.13.1 Tuning the Servo Gains
8-78
Pn409
First Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn40A
First Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn40B
First Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn40C
Second Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn40D
Second Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn40E
Second Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn417
Third Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn418
Third Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn419
Third Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn41A
Fourth Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn41B
Fourth Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn41C
Fourth Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn41D
Fifth Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn41E
Fifth Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn41F
Fifth Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
