12.4 Speed/Position Expansion Function Setting
12.4.3 Program Tables, ZONE Tables, and JOG Speed Tables
12-10
 Read Commands
ZONE Tables
 Write Commands
 Read Commands
DECTsss =
nnnnnnnn
1 ≤ nnnnnnnn ≤ 99,999,999
[1,000 (reference units/min)/ms]
DECTsss =
nnnnnnnnn
1 ≤ nnnnnnnnn ≤ 199,999,999
[1,000 (reference units/min)/ms]
Serial
Command
Display (Acknowledgment)
PnB54 = 0 (Disable Expansion Mode) PnB54 = 1 (Enable Expansion Mode)
POSTsss
POST123 = A + 12345678 [CR] [LF]
POST123 = I + 12345678 [CR] [LF]
POST123 = S + 12345678 [CR] [LF]
POST123 = +INFINITE [SP] [CR] [LF]
POST123 = STOP [SP] [SP] [SP] [SP] [SP]
[SP] [CR] [LF]
POST123 = -[SP] [SP] [SP] [SP] [SP] [SP]
[SP] [SP] [SP] [CR] [LF]
POST123 = A + 1234567890 [CR] [LF]
POST123 = I + 1234567890 [CR] [LF]
POST123 = S + 1234567890 [CR] [LF]
POST123 = +INFINITE [SP] [SP] [SP] [CR]
[LF]
POST123 = STOP [SP] [SP] [SP] [SP] [SP]
[SP] [SP] [SP] [CR] [LF]
POST123 = -[SP] [SP] [SP] [SP] [SP] [SP]
[SP] [SP] [SP] [SP] [SP] [CR] [LF]
SPDTsss SPDT123 = 12345678 [CR] [LF] SPDT123 = 1234567890 [CR] [LF]
RDSTTsss
RDSTT123 = 12345678 [CR] [LF]
RDSTT123 = -[SP] [SP] [SP] [SP] [SP] [SP]
[SP] [CR] [LF]
RDSTT123 = 1234567890 [CR] [LF]
RDSTT123 = -[SP] [SP] [SP] [SP] [SP] [SP]
[SP] [SP] [SP] [CR] [LF]
RSPDTsss RSPDT123 = 12345678 [CR] [LF] RSPDT123 = 1234567890 [CR] [LF]
ACCTsss
ACCTsss = 12345678 [CR] [LF]
ACCTsss = : [SP] [SP] [SP] [SP] [SP] [SP]
[SP] [CR] [LF]
ACCTsss = 1234567890 [CR] [LF]
ACCTsss = : [SP] [SP] [SP] [SP] [SP] [SP]
[SP] [SP] [SP] [CR] [LF]
DECTsss
DECTsss = 12345678 [CR] [LF]
DECTsss = : [SP] [SP] [SP] [SP] [SP] [SP]
[SP] [CR] [LF]
DECTsss = 1234567890 [CR] [LF]
DECTsss = : [SP] [SP] [SP] [SP] [SP] [SP]
[SP] [SP] [SP] [CR] [LF]
PnB54 = 0 (Disable Expansion Mode) PnB54 = 1 (Enable Expansion Mode)
Serial Command Setting Range Serial Command Setting Range
ZONEPTzz =
nnnnnnnn
-99,999,999
≤ nnnnnnnn ≤
+99,999,999
ZONEPTzz =
nnnnnnnnnn
-1,073,741,823
≤ nnnnnnnnnn
≤ +1,073,741,823
ZONENTzz =
nnnnnnnn
-99,999,999
≤ nnnnnnnn ≤
+99,999,999
ZONENTzz =
nnnnnnnnnn
-1,073,741,823 ≤ nnnnnnnnnn
≤ +1,073,741,823
Serial
Command
Display (Acknowledgment)
PnB54 = 0 (Disable Expansion Mode) PnB54 = 1 (Enable Expansion Mode)
ZONEPTzz ZONEPT123 = +12345678 [CR] [LF] ZONEPT123 = +1234567890 [CR] [LF]
ZONENTzz ZONENT123 = +12345678 [CR] [LF] ZONENT123 = +1234567890 [CR] [LF]
Continued from previous page.
PnB54 = 0 (Disable Expansion Mode) PnB54 = 1 (Enable Expansion Mode)
Serial
Command
Setting Range
Serial
Command
Setting Range
