13.4 Jog Speed Table Operation
13.4.4 SigmaWin+ Procedures
13-46
Editing the Jog Speed Table
Displaying the Jog Speed Table Editing Dialog Box
Select Edit Jog Speed Table in the Menu Dialog Box of the SigmaWin+.
Details on the Jog Speed Table Editing Dialog Box
No. Item Description
Save Button Saves the currently displayed settings to a computer file.
Print Button Prints the currently displayed settings.
Setting Area
Set the jog speeds.
Select the cell and enter the value directly.
Comment Button Lets you add a comment.
Import Button Imports a jog speed table from a file saved on the computer to the SigmaWin+.
Initialize Button Initializes the flash memory in the SERVOPACK.
Save Button Saves the settings in the SERVOPACK to flash memory.
Read Button Reads the settings in the SERVOPACK to the SigmaWin+.
Write Button Writes the currently displayed settings to the SERVOPACK.
