15.4 Troubleshooting Based on the Operation and Conditions of the Servomotor
15-77
15
Maintenance
Position
Deviation
(without
Alarm)
Noise interference occurred
because of incorrect Encoder
Cable specifications.
Turn OFF the power sup-
ply to the servo system.
Check the Encoder Cable
to see if it satisfies speci-
fications. Use a shielded
twisted-pair wire cable or
a screened twisted-pair
cable with conductors of
at least 0.12 mm
2
.
Use cables that satisfy
the specifications.
Noise interference occurred
because the Encoder Cable
is too long.
Turn OFF the power sup-
ply to the servo system.
Check the length of the
Encoder Cable.
Rotary Servomotors:
The Encoder Cable
length must be 50 m
max.
Linear Servomotors:
Make sure that the
Serial Converter Unit
cable is no longer
than 20 m and that
the Linear Encoder
Cable and the Sensor
Cable are no longer
than 15 m each.
Noise interference occurred
because the Encoder Cable
is damaged.
Turn OFF the power sup-
ply to the servo system.
Check the Encoder Cable
to see if it is pinched or
the sheath is damaged.
Replace the Encoder
Cable and correct the
cable installation envi-
ronment.
The Encoder Cable was sub-
jected to excessive noise
interference.
Turn OFF the power sup-
ply to the servo system.
Check to see if the
Encoder Cable is bundled
with a high-current line or
installed near a high-cur-
rent line.
Correct the cable lay-
out so that no surge is
applied by high-current
lines.
There is variation in the FG
potential because of the
influence of machines on the
Servomotor side, such as a
welder.
Turn OFF the power sup-
ply to the servo system.
Check to see if the
machines are correctly
grounded.
Properly ground the
machines to separate
them from the FG of
the encoder.
There is a SERVOPACK
pulse counting error due to
noise.
Turn OFF the power sup-
ply to the servo system.
Check to see if there is
noise interference on the
I/O signal line from the
encoder or Serial Con-
verter Unit.
Implement counter-
measures against noise
for the encoder wiring
or Serial Converter Unit
wiring.
Continued on next page.
Continued from previous page.
Problem Possible Cause Confirmation Correction Reference
