YASKAWA E-7S SERVOPACK SGD7S - Page 82

2.3 External Dimensions
2.3.2 SERVOPACK External Dimensions
2-21
2
Selecting a SERVOPACK
•
Three-phase, 200 VAC: SGD7S-2R8A; Single-phase, 100 VAC: SGD7S-R70F, -R90F, and -2R1F
•
Three-phase, 200 VAC: SGD7S-3R8A, -5R5A, and -7R6A; Single-phase, 100 VAC: SGD7S-2R8F
•
Three-phase, 200 VAC: SGD7S-120A
Ground
terminals
2 × M4
160 ±0.5 (mounting pitch)
Exterior
20 ±0.5 (mounting pitch)
Mounting Hole Diagram
Unit: mm
Approx. mass: 1.0 kg
160
168
8
40
170
18
(4)
(75)
168
5
2 × M4
40
5
(25)
Two sets of terminals
Ground
terminals
2 × M4
58 ±0.5 (mounting pitch)
160 ±0.5 (mounting pitch)
Exterior
Mounting Hole Diagram
Unit: mm
Approx. mass: 1.6 kg
Two sets of terminals
160
168
8
70
180
(75)
18
(4)
70
6
168
3 × M4
5
(25)
Two sets of terminals
Ground
terminals
2 × M4
160 ±0.5 (mounting pitch)
Exterior
Mounting Hole Diagram
Unit: mm
Approx. mass: 2.2 kg
160
168
8
90
180
(75)
18
(25)
(4)
168
5
3 × M4
90
12.5
80±0.5 (mounting pitch)
5
