4.2 Preparation (step 1)
4.2.1 Wiring
4-4
[ a ] Required Equipment
Caution
• Install MPE720 Ver.6 in the personal computer before starting step 1.
For information on its installation, refer to Engineering Tool for MP2000 series Machine Controller MPE720 Version 6 Users
Manual (manual number: SIEP C880700 30).
• Set the PC Ethernet port in advance. For information on the setup, refer to Appendix F Simple Connection Function of the
Engineering Tool.
• The SERVOPACK station number (SW1) is set to 1 and 2.
• In a 1:1 connection without HUB, use a cross cable as a LAN cable.
Product Name Model Q’ty
MP2300S
JEPMC-MP2300S-E
1
MECHATROLINK cable (0.5m)
JEPMC-W6002-A5
2
Terminator (terminating resistor)
JEPMC-W6022
2
Σ-III SERVOPACK
SGDS-A5F12A
2
Σ-III servomotor
SGMAS-A5A2A21
2
Motor cable (3m)
JZSP-CSM01-03
2
Encoder cable (3m)
JZSP-CSP05-03
2
HUB (commercial product)
LSW-TX-8EP
1
MPE720 Ver.6
CPMC-MPE770
1
LAN cable (for Ethernet connection)
Commercial straight cable
2
Personal computer (main unit)
Commercial product
1
24-VDC
Current capacity of power supply 2A or more
1
To Next Page
