3.2 Basic Module Connections
3.2.5 RLY OUT Connector Details
3-23
3.2.5 RLY OUT Connector Details
The RLY OUT connector is a terminal for outputting state and NO contact relay output. A circuit between terminals is
short-circuited when RDY LED is lit, and opens when it is unlit.
Note: A state when RDY LED is lit indicates that a controller is operating normally. It does not indicate that an
user program is running.
( 1 ) RLY OUT Connector Specifications and Pin Arrangement
The following table provides the RLY OUT connector specifications.
The following table shows the RLY OUT connector pin arrangement.
The following table provides the RLY OUT connector contact ratings.
( 2 ) RLY OUT Connection Cable
For the RLY OUT connection cable, use a cable of line size AWG28 to AWG14 (0.08 mm
2
to 1.5 mm
2
), maximum
sheath diameter φ3.4 mm.
The manufacturing procedures for the RLY OUT connection cable and the 24-VDC power supply cable are similar.
Name
Connector
Name
Number
of Pins
Connector Model
Module Side Cable Side Manufacturer
RLY OUT RLY OUT
2 734-162 734-YE102 Wago Corporation
Pin Number Signal Name Description
1OUT
• Operating normally: Short-circuit
• Error occurred: Opened
2OUT
Input Voltage Current Capacity
24 VDC
0.5 A (resistance load)
0.25 A (induced load)
125 VAC
0.4 A (resistance load)
0.2 A (induced load)
RLY
OU
