1.4 MECHATROLINK Compatible Devices
1.4.2 MECHATROLINK-III Compatible Devices
1-8
1.4.2 MECHATROLINK-III Compatible Devices
The following devices support MECHATROLINK communications and can be connected to the MECHATROLINK
connector of the SVC-01 Module.
( 1 ) SERVOPACKs
( 2 ) Modules
JEPMC-IO2310
64-point I/O Module
24 VDC, 64 inputs, 64 outputs (sink mode
output)
Yes Yes
JEPMC-IO2330
64-point I/O Module
24 VDC, 64 inputs, 64 outputs (source
mode output)
Yes Yes
JEPMC-PL2900
Counter Module
Reversible counter, 2 channels
Yes Yes
JEPMC-PL2910
Pulse Output Module
Pulse output, 2 channels
Yes Yes
JEPMC-AN2900
A/D Module
Analog inputs, 10 to 10 V, 4 channels
Yes Yes
JEPMC-AN2910
D/A Module
Analog outputs, 10 to 10 V, 2 channels
Yes Yes
JAPMC-MC2310 SVB-01 Motion Module
Yes Yes
JEPMC-REP2000 MECHATROLINK-II Repeater
No Yes
JEVSA-YV250 MYVIS (image processing device)
Yes Yes
JEPMC-MC400 MP940 Motion Controller
Yes No
(cont’d)
Model Description MECHATROLINK-I MECHATROLINK-II
Model Description
SGDV-21
SGDV SERVOPACK MECHATROLINK-III Communications
reference/rotational
SGDV-25
SGDV SERVOPACK MECHATROLINK-III Communications
reference/linear
Model Description
JAPMC-MC2320-E
SVC-01 Motion Module
