6.4 Communication with PLC Manufactured by Mitsubishi Electric Corporation (MELSEC protocol)
6.4.2 When the MP2300S Acts as Master (I/O message communication function is used)
6-83
Built-in Ethernet Communications
6.4.2 When the MP2300S Acts as Master (I/O message communication function is
used)
This section explains how to carry out the communications between CPU and the MELSEC Q series using the
MP2300S I/O message communication function.
Fig. 6.13 Message Flow with MELSEC Q series when I/O Message Communication Function Is Used
Caution
I/O message communication is 1:1 communication.
In addition, you can read and write the registers below using inter-CPU communication when “Communication Protocol Type:
MELSEC” is used in the communication with the MELSEC series.
Bit device register - - - - X, Y (read only), M, B
Word device register - - - D, W, R
Note: A bit device register reads or writes on a per-word (16 bit) basis.
When communicating with multiple remote devices.
To carry out a fixed buffer/random access buffer communication when reading/writing registers other than those mentioned
above, use the message transmit function (MSG-SND).
MELSEC Q series
(Remote station)
MELSEC protocol
(inter-CPU communication)
MP2300S
218IFA
I/O Message
Communication Function
(ladderless)
MP
/
E
thernet
LINK
0
0
23
S
&%
&%
8
4.;
176
0V
;#5-#9#
6'56
4&;
#./
/6:
64:
470
'44
$#6
+2
59
59
10
10
%0()
+06
572
/10
5612
$#66'4;
M-I/II
'
'
6'56
+06
01
01
MELSEC Q series
MP2300S
(Local station)
Slave
Master
Communication Protocol
Type
Connection Type
Data Code Type
MELSEC protocol
TCP / UDP
BIN / ASCII
EthernetEthernet
