1.5 Cables and Accessories
1.5.1 Cables
1-9
Overview
1.5 Cables and Accessories
1.5.1 Cables
The following table shows the cables that can be connected to the MP2300S Basic Module and Optional Modules.
Module
Connector
Name
Application Model Specifications
MP2300S
Basic Module
Ethernet
Ethernet communication
cable
Provided by customers.
–
MP2300S
Basic Module
and SVB-01
M-I/II
MECHATROLINK-I
cable
JEPMC-W6010-
*with a MECHATROLINK
connector and loose
wires
Used between the devices listed below
SVB-01 and SGD-N
SVB-01 and SGDB-AN
MECHATROLINK-I
terminator
JEPMC-W6020 –
MECHATROLINK-II
cable
JEPMC-W6002-
*with MECHATROLINK
connectors on both ends
Used between the devices listed below
SVB-01 and I/O Unit,
SVB-01 and SGDH-E+NS100
SVB-01 and SGDH-E+NS115
SVB-01 and SGDS-1
SVB-01 and SGDV-11
SVB-01 and SGDV-15
JEPMC-W6003-
*with MECHATROLINK
connectors on both ends
*with ferrite core
MECHATROLINK-II
terminator
JEPMC-W6022 –
SVA-01 CN1, CN2
Cable for analog reference
input SERVOPACK
JEPMC-W2040-
Used between the devices listed below
SVA-01 and SGDM/SGDH
SVA-01 and SGDS-01
SVA-01 and SGDS-02
LIO-01/
LIO-02
I/O
External I/O cable
JEPMC-W2061-
*Loose wires on one end
Used between
LIO-01/LIO-02 and external I/O device
LIO-04/
LIO-05
CN1, CN2
External I/O cable
JEPMC-W6060-
*Loose wires on one end
Used between
LIO-04/LIO-05 and external I/O device
LIO-06 CN1
External I/O cable
JEPMC-W2064-
*Loose wires on one end
Used between
LIO
-
06 and external I/O device
DO-01 CN1, CN2
External output cable
JEPMC-W6060-
*Loose wires on one end
Used between
DO-01 and external I/O device
AI-01 CN1, CN2
Analog input cable
JEPMC-W6080-
*Loose wires on one end
Used between
AI-01 and analog external input device
AO-01 CN1
Analog output cable
JEPMC-W6090-
*Loose wires on one end
Used between
AO-01 and analog external output device
CNTR-01 CN1
Cable for CNTR-01 Module
JEPMC-W2063E-
*Loose wires on one end
Used between
CNTR-01 and external I/O device
