6.2 Communication with Other MP Series
6.2.1 When the MP2300S Acts as Slave (automatic receive function is used)
6-9
Built-in Ethernet Communications
( 2 ) How to Set up the Remote Device (MP2300) to Be Connected
If the setting of transmission parameters (IP address, subnet mask) is already completed, start from step 3.
1. Double-click the 218IF Tab in the Module Details of the module configuration definition.
2. Set transmission parameters.
How to set up transmission parameters
c Set IP Address (“192.168.001.001,” for example).
d Click Edit, and then click Local Station: TCP/IP Setting in the Engineering Manager Window.
c
e f
