1.4 MECHATROLINK Compatible Devices
1.4.1 MECHATROLINK-I/II Compatible Devices
1-7
Overview
1.4 MECHATROLINK Compatible Devices
1.4.1 MECHATROLINK-I/II Compatible Devices
The following devices support MECHATROLINK communications and can be connected to the MECHATROLINK
connectors of the MP2300S and SVB-01 Module.
( 1 ) SERVOPACKs and Inverters
( 2 ) Modules
Drive
Type
Model Description MECHATROLINK-I MECHATROLINK-II
SGD-N
SGDB-AN
MECHATROLINK compatible AC SERVO-
PACKs
Yes No
SGDH-E
JUSP-NS100
SGDH SERVOPACK
NS100 MECHATROLINK-I Interface Units
Yes No
SGDH-E
JUSP-NS115
SGDH SERVOPACK
NS115 MECHATROLINK-II Interface Units
Yes Yes
SGDS-1
SGDS SERVOPACKs
Yes Yes
SGDX-1
SGDX SERVOPACKs
Yes Yes
SJDE-AN
SJDE SERVOPACKs
No Yes
SGDV-1
SGDV SERVOPACKs
Yes Yes
JUSP-IM
MECHATROLINK-II compatible IDMs
No Yes
CIMR-G7A
SI-T
Varispeed G7 Inverters
MECHATROLINK interface
Yes Yes
CIMR-F7A
SI-T
Varispeed F7 Inverters
MECHATROLINK interface
Yes Yes
CIMR-V7AA
SI-T/V7
Varispeed V7 Inverters
MECHATROLINK interface
Yes Yes
Model Description MECHATROLINK-I MECHATROLINK-II
JEPMC-IO350
64-point I/O Module
24 VDC, 64 inputs, 64 outputs
Yes No
JAMSC-120DDI34330
DC Input Module
12/24 VDC, 16 inputs
Yes No
JAMSC-120DDO34340
DC Output Module
12/24 VDC, 16 outputs
Yes No
JAMSC-120DAI53330
AC Input Module
100 VAC, 8 inputs
Yes No
JAMSC-120DAI73330
AC Input Module
200 VAC, 8 inputs
Yes No
JAMSC-120DAO83330
AC Output Module
100/200
V
AC, 8 outputs
Yes No
JAMSC-120DRA83030
Relay Module
Wide voltage range relay contacts,
8 contact outputs
Yes No
JAMSC-120AVI02030
A/D Module
Analog inputs, 10 to 10 V, 4 channels
Yes No
JAMSC-120AVO01030
D/A Module
Analog outputs, 10 to 10 V, 2 channels
Yes No
JAMSC-120EHC21140
Counter Module
Reversible counter, 2 channels
Yes No
JAMSC-120MMB20230
Pulse Output Module
Pulse output, 2 channels
Yes No
JAMSC-IO2900-E
DC Input Module
12/24 VDC, 16 inputs
Yes Yes
JAMSC-IO2910-E
DC Output Module
12/24 VDC, 16 outputs
Yes Yes
SERVOPACKs
Inverters
