Appendix A System Registers Lists
A.9 Interrupt Status
A-14
A.9 Interrupt Status
A.9.1 Interrupt Status List
A.9.2 Details on Interrupting Module
( 1 ) Rack
mm = 01 to 04 (01 only for the MP2300 module)
The number of the rack where the module that caused the interrupt is mounted is reported.
( 2 ) Slot
ss = 01 to 09
( 3 ) Interrupt type
1: CPU IO (MP2100, MP2100M, MP2101, MP2101M, MP2101T, MP2101TM, MP2300): DI interrupt
2: LIO-01/LIO-02/LIO-04/LIO-05: DI interrupt
3: LIO-01/LIO-02/LIO-06/CNTR-01: Counter interrupt
Name Register No. Remarks
Interrupt information
SW00698
Interrupt detection count
SW00699
Number of interrupting modules
SW00700
SW00701
Interrupting module 1
SW00702
SW00703
SW00704
Interrupting module 2
SW00705
:
:
SW00787
SW00788
Interrupting module 30
SW00789
F 8 7 0
(Bit number)
SW00xx+0 Rack Slot
mmssH
SW00xx+1 Interrupt type
SW00xx+2 Hardware interrupt cause register value
