2.4 External Appearance
2.4.2 Basic Module with Metal Fittings
2-65
Specifications and Functions
2.4.2 Basic Module with Metal Fittings
/25
2 x
φ
5 holes
Approx. 8
when attached
88
76
(42) 111.5
108 3.5
66
4.54.5 121
130
5
Units: mm
