1.5 Cables and Accessories
1.5.2 Accessories and Options
1-10
1.5.2 Accessories and Options
1.5.3 Software (Programming Tool)
The MPE720, programming tool for MP2300S, is available.
Communica-
tion Module
PORT
(Common to all
communica-
tion modules)
RS-232C communication
cable
JEPMC-W5310-
Used between
RS-232C port and 25-pin male D-sub
connector
JEPMC-W5311-
Used between
RS-232C port and DOS/V
218IF-01 10Base-T
Ethernet communication
cable
Use a commercially avail-
able cable.
Cross cable (Category 3 min.)
218IF-02 Ethernet
Cross or straight cable (Category 5)
217IF-01 RS-422/485
RS-422/RS-485 communica-
tion cable
Module-side connector:
1010214-52A2JL (manufactured by 3M
Japan Limited)
Cable-side connector:
10114-3000PE (manufactured by 3M
Japan Limited)
Shell: 10314-52A0-008 (manufactured
by 3M Japan Limited)
260IF-01 DeviceNet
DeviceNet communication
cable
Module-side connector:
MSTB2-5/5-GF-5.08AM
(manufactured by Phoenix Contact K.K.)
261IF-01 PROFIBUS
PROFIBUS communication
cable
Module-side connector:
17LE-13090-27(D33C) (manufactured
by DDK Ltd.)
262IF-01 FL-net
Ethernet communication
cable
Cross or straight cable
(Category 5)
263F-01 EtherNet/IP
Name Accessory/Optional Model Remarks
Battery Accessory JZSP-BA01
ER3VC + exclusive use connector
(BA000517)
Power Supply Connector Accessory 721-203/026 Cable side
RLY OUT Connector Accessory 734-YE102-2 Cable side
DIN Rail Mounting Parts Accessory
DIN rail spring Q’ty: 2
DIN rail lock Q’ty: 2
Terminator
(Terminating Resistor)
Accessory JEPMC-W6022
Q’ty: 1
Metal Fittings for Attachment Optional JEPMC-OP2300S-E
Optional Cover Optional JEPMC-OP2300 Front cover for the empty slot
(cont’d)
Module
Connector
Name
Application Model Specifications
Name Model Remarks
MPE720
CPMC-MPE720 (Ver. 5.38 or later) CD-ROM (1 disk)
MPE720 Version 6
CPMC-MPE720 (Ver. 6.04 or later) CD-ROM (1 disk)
