6.4 Communication with PLC Manufactured by Mitsubishi Electric Corporation (MELSEC protocol)
6.4.1 When the MP2300S Acts as Slave (automatic receive function is used)
6-81
Built-in Ethernet Communications
( 2 ) How to Set up the Remote Device (MELSEC Q series) to Be Connected
This section explains the MELSEC Q series side procedure to set up for connecting the MP2300S with the MELSEC Q
series.
Note: MELSEC Q series are manufactured by Mitsubishi Electric Corporation.
Contact Mitsubishi Electric Corporation for more information.
1. Start up GX Developer.
2. Create a new project.
3. Set up network parameters (MELSECNET/Ethernet).
4. Set up Ethernet operation.
5. Set the open setting.
Table 6.22 Network Parameter Setting (example)
Setting Item Setting Details
Network Type Ethernet
Start I/O No. Any
Network No. Any
Group No. Any
Exchange Number Any
Mode Online
Table 6.23 Ethernet Operation Setting (example)
Setting Item Setting Details
Communication Data Code
Setting
Binary code communication
Initial Timing Setting Any
IP Address 192.168.1.2
Transmit Frame Setting Ethernet (V2.0)
TCP Alive Check Setting Any
Permit Writing during RUN Permitted
Table 6.24 Open Setting (example)
Setting Item
Setting Details
(connection number=1)
Protocol TCP
Open System Active
Fixed Buffer Transmit
Procedure to Communicate with Fixed Buffer With procedure
Pairing Open Any
Check Alive Any
Local Port Number 2711H (10001)
Remote IP Address for Communications 192.168.1.1
Remote Port Number for Communications 2711H (10001)
