YASKAWA MP2300S User Manual

2.2 Basic Module
2.2.2 External Appearance, LED Indicators, and Switch Settings
2-9
Specifications and Functions
( 3 ) Switch Settings
The DIP switch sets the operating conditions for the Basic Module when the power is turned ON.
[ a ] SW1
No. Name Setting Operating Mode Default Details
S1-6 STOP
ON User program stopped
OFF
Stops the user program execution. Enabled only
when the power is turned ON.
OFF User program running
S1-5 SUP
ON System load
OFF
If set to ON, starts in a mode that can change the
version.
OFF Normal operation
S1-4 INIT
ON Memory clear
OFF
Set to ON to clear the memory. If this switch is set
to OFF, the program stored in flash memory will
be executed.
OFF Normal operation
S1-3 CNFG
ON Self-configuration mode
OFF
Set to ON to execute self-configuration for con-
nected devices.
OFF Normal operation
S1-2 MON
ON System use
OFF
Always leave set to OFF.
OFF Normal operation
S1-1 TEST
ON System use
OFF
Always leave set to OFF.
OFF Normal operation
SW
1
TEST
MON
CNFG
INT
SUP
STOP
NO
