4.5 Starting Motion Program from an External Signal
4.5.3 Creation Procedure
4-17
System Start Up and Easy Programming
• Click the Save Icon to save the M-EXECUTOR definition.
3. Communication Setting with Touch Panel
For information on communication setting with the touch panel, refer to 6.3 Communication with Touch Panel.
4. FLASH Save
When all settings are completed, click the FLASH Save Icon to save the data to the flash memory.
5. Operation Check
Turn ON MP2300S power again and press “c Servo” and “d Start” on the panel screen.
Then check that the motion program starts and the two-axes motor begins to operate to change the current posi-
tion of the axis.
