2.2 Basic Module
2.2.5 Built-in SVB Module
2-39
Specifications and Functions
The following table lists the items shown in the Module Configuration Window.
“Possible” in the Modification line in the above table means that it is possible to change the setting of the item.
Always save the setting to the flash memory after having changed the setting.
When changing the setting, be careful not to set the register numbers overlapped with another module.
I/O Start Register and I/O End Register must be set even though the I/O Module is connected or not connected
to MECHATROLINK.
Item Description Modification
Slot Number
Slot number Not possible
Module Type
Module detected in the slot Possible
Controller Number
Fixed to 01 Not possible
Circuit Number
Module circuit number Possible
I/O Start Register
I/O start register number of the I/O Module to be connected to MECHA-
TROLINK
(Setting range: 0000 to 7FFFh, max. 400h words per SVB Module)
Possible
I/O End Register
I/O last register number of the I/O Module to be connected to MECHA-
TROLINK
(Setting range: 0000 to 7FFFh, max. 400h words per SVB Module)
Possible
Disable Input
Input enabled (Enable)/disabled (Disable)
Possible
(Not possible
if the cell is
blank)
Disable Output
Output enabled (Enable)/disabled (Disable)
Possible
(Not possible
if the cell is
blank)
Motion Start Register
Start register number of the motion parameters
(Automatically sets according to the circuit number)
Not possible
Motion End Register
Last register number of the motion parameters
(Automatically sets according to the circuit number)
Not possible
Details
Opens the MECHATROLINK Transmission Definition Window.
(Double-click the MECHATROLINK cell to open the window.)
−
Status
Status of each module in online mode Not possible
